Dialog
A window overlaid on either the primary window or another dialog window, rendering the content underneath inert.
Usage
Example
Dialog do
DialogTrigger do
Button { "Open Dialog" }
end
DialogContent do
DialogHeader do
DialogTitle { "RubyUI to the rescue" }
DialogDescription { "RubyUI helps you build accessible standard compliant web apps with ease" }
end
DialogMiddle do
AspectRatio(ratio: "16/9", class: 'rounded-md overflow-hidden border') do
img(
alt: "Placeholder",
class: "absolute inset-0 size-full object-cover",
loading: "lazy",
src: image_path("pattern.jpg")
)
end
end
DialogFooter do
Button(variant: :outline, data: { action: 'click->ruby-ui--dialog#dismiss' }) { "Cancel" }
Button { "Save" }
end
end
end
Size
Without a size, the dialog fills the viewport width up to 28rem (max-w-md) on wider screens. The sizes below apply on wider screens.
div(class: 'flex flex-wrap justify-center gap-2') do
Dialog do
DialogTrigger do
Button { "Small Dialog" }
end
DialogContent(size: :sm) do
DialogHeader do
DialogTitle { "RubyUI to the rescue" }
DialogDescription { "RubyUI helps you build accessible standard compliant web apps with ease" }
end
DialogMiddle do
AspectRatio(ratio: "16/9", class: 'rounded-md overflow-hidden border') do
img(
alt: "Placeholder",
class: "absolute inset-0 size-full object-cover",
loading: "lazy",
src: image_path("pattern.jpg")
)
end
end
DialogFooter do
Button(variant: :outline, data: { action: 'click->ruby-ui--dialog#dismiss' }) { "Cancel" }
Button { "Save" }
end
end
end
Dialog do
DialogTrigger do
Button { "Large Dialog" }
end
DialogContent(size: :lg) do
DialogHeader do
DialogTitle { "RubyUI to the rescue" }
DialogDescription { "RubyUI helps you build accessible standard compliant web apps with ease" }
end
DialogMiddle do
AspectRatio(ratio: "16/9", class: 'rounded-md overflow-hidden border') do
img(
alt: "Placeholder",
class: "absolute inset-0 size-full object-cover",
loading: "lazy",
src: image_path("pattern.jpg")
)
end
end
DialogFooter do
Button(variant: :outline, data: { action: 'click->ruby-ui--dialog#dismiss' }) { "Cancel" }
Button { "Save" }
end
end
end
end
Installation
Using RubyUI CLI
Run the install command
rails g ruby_ui:component Dialog
Manual installation
1
Add RubyUI::Dialog to app/components/ruby_ui/dialog/dialog.rb
# frozen_string_literal: true
module RubyUI
class Dialog < Base
def initialize(open: false, **attrs)
@open = open
super(**attrs)
end
def view_template(&)
div(**attrs, &)
end
private
def default_attrs
{
data: {
controller: "ruby-ui--dialog",
ruby_ui__dialog_open_value: @open
}
}
end
end
end
2
Add RubyUI::DialogContent to app/components/ruby_ui/dialog/dialog_content.rb
# frozen_string_literal: true
module RubyUI
class DialogContent < Base
SIZES = {
xs: "max-w-sm",
sm: "max-w-md",
md: "max-w-lg",
lg: "max-w-2xl",
xl: "max-w-4xl",
full: "max-w-full"
}
DEFAULT_WIDTH = "max-w-[calc(100%-2rem)] sm:max-w-md"
def initialize(size: nil, show_close_button: true, **attrs)
@size = size
@show_close_button = show_close_button
super(**attrs)
end
def view_template
dialog(**attrs) do
yield
close_button if @show_close_button
end
end
private
def default_attrs
{
data_ruby_ui__dialog_target: "dialog",
data_action: "pointerdown->ruby-ui--dialog#backdropPointerdown click->ruby-ui--dialog#backdropClick",
class: [
"fixed open:grid top-1/2 left-1/2 -translate-x-1/2 -translate-y-1/2 z-50 w-full gap-6 rounded-xl bg-popover p-6 text-sm text-popover-foreground outline-none ring-1 ring-foreground/10 backdrop:bg-black/10 supports-backdrop-filter:backdrop:backdrop-blur-xs",
"duration-100 data-[state=open]:animate-in data-[state=open]:fade-in-0 data-[state=open]:zoom-in-95 data-[state=closed]:animate-out data-[state=closed]:fade-out-0 data-[state=closed]:zoom-out-95 data-[state=closed]:fill-mode-forwards motion-reduce:animate-none!",
"backdrop:duration-100 data-[state=open]:backdrop:animate-in data-[state=open]:backdrop:fade-in-0 data-[state=closed]:backdrop:animate-out data-[state=closed]:backdrop:fade-out-0 data-[state=closed]:backdrop:fill-mode-forwards motion-reduce:backdrop:animate-none!",
SIZES.fetch(@size, DEFAULT_WIDTH)
]
}
end
def close_button
button(
type: "button",
class: "absolute top-4 end-4 size-8 shrink-0 rounded-[min(var(--radius-md),10px)] inline-flex items-center justify-center border border-transparent bg-clip-padding whitespace-nowrap outline-none select-none transition-all hover:bg-muted hover:text-foreground dark:hover:bg-muted/50 aria-expanded:bg-muted aria-expanded:text-foreground focus-visible:border-ring focus-visible:ring-3 focus-visible:ring-ring/50 active:not-aria-[haspopup]:translate-y-px disabled:pointer-events-none disabled:opacity-50 [&_svg]:pointer-events-none [&_svg]:shrink-0 [&_svg]:size-4",
data_action: "click->ruby-ui--dialog#dismiss"
) do
svg(
xmlns: "http://www.w3.org/2000/svg",
viewbox: "0 0 24 24",
fill: "none",
stroke: "currentColor",
stroke_width: "2",
stroke_linecap: "round",
stroke_linejoin: "round",
aria_hidden: "true"
) do |s|
s.path(d: "M18 6 6 18")
s.path(d: "m6 6 12 12")
end
span(class: "sr-only") { "Close" }
end
end
end
end
3
Add RubyUI::DialogDescription to app/components/ruby_ui/dialog/dialog_description.rb
# frozen_string_literal: true
module RubyUI
class DialogDescription < Base
def view_template(&)
p(**attrs, &)
end
private
def default_attrs
{
class: "text-sm text-muted-foreground *:[a]:underline *:[a]:underline-offset-3 *:[a]:hover:text-foreground",
data_ruby_ui__dialog_target: "description"
}
end
end
end
4
Add RubyUI::DialogDocs to app/components/ruby_ui/dialog/dialog_docs.rb
# frozen_string_literal: true
class Views::Docs::Dialog < Views::Base
def view_template
component = "Dialog"
div(class: "max-w-2xl mx-auto w-full py-10 space-y-10") do
render Docs::Header.new(title: "Dialog", description: "A window overlaid on either the primary window or another dialog window, rendering the content underneath inert.")
Heading(level: 2) { "Usage" }
render Docs::VisualCodeExample.new(title: "Example", context: self) do
<<~RUBY
Dialog do
DialogTrigger do
Button { "Open Dialog" }
end
DialogContent do
DialogHeader do
DialogTitle { "RubyUI to the rescue" }
DialogDescription { "RubyUI helps you build accessible standard compliant web apps with ease" }
end
DialogMiddle do
AspectRatio(ratio: "16/9", class: 'rounded-md overflow-hidden border') do
img(
alt: "Placeholder",
class: "absolute inset-0 size-full object-cover",
loading: "lazy",
src: image_path("pattern.jpg")
)
end
end
DialogFooter do
Button(variant: :outline, data: { action: 'click->ruby-ui--dialog#dismiss' }) { "Cancel" }
Button { "Save" }
end
end
end
RUBY
end
render Docs::VisualCodeExample.new(title: "Size", description: "Without a size, the dialog fills the viewport width up to 28rem (max-w-md) on wider screens. The sizes below apply on wider screens.", context: self) do
<<~RUBY
div(class: 'flex flex-wrap justify-center gap-2') do
Dialog do
DialogTrigger do
Button { "Small Dialog" }
end
DialogContent(size: :sm) do
DialogHeader do
DialogTitle { "RubyUI to the rescue" }
DialogDescription { "RubyUI helps you build accessible standard compliant web apps with ease" }
end
DialogMiddle do
AspectRatio(ratio: "16/9", class: 'rounded-md overflow-hidden border') do
img(
alt: "Placeholder",
class: "absolute inset-0 size-full object-cover",
loading: "lazy",
src: image_path("pattern.jpg")
)
end
end
DialogFooter do
Button(variant: :outline, data: { action: 'click->ruby-ui--dialog#dismiss' }) { "Cancel" }
Button { "Save" }
end
end
end
Dialog do
DialogTrigger do
Button { "Large Dialog" }
end
DialogContent(size: :lg) do
DialogHeader do
DialogTitle { "RubyUI to the rescue" }
DialogDescription { "RubyUI helps you build accessible standard compliant web apps with ease" }
end
DialogMiddle do
AspectRatio(ratio: "16/9", class: 'rounded-md overflow-hidden border') do
img(
alt: "Placeholder",
class: "absolute inset-0 size-full object-cover",
loading: "lazy",
src: image_path("pattern.jpg")
)
end
end
DialogFooter do
Button(variant: :outline, data: { action: 'click->ruby-ui--dialog#dismiss' }) { "Cancel" }
Button { "Save" }
end
end
end
end
RUBY
end
render Docs::VisualCodeExample.new(title: "Close button", description: "DialogContent shows a close button in the corner by default. Pass show_close_button: false to hide it, and show_close_button: true on DialogFooter to add a Close button to the footer.", context: self) do
<<~RUBY
Dialog do
DialogTrigger do
Button { "Open Dialog" }
end
DialogContent(show_close_button: false) do
DialogHeader do
DialogTitle { "RubyUI to the rescue" }
DialogDescription { "RubyUI helps you build accessible standard compliant web apps with ease" }
end
DialogFooter(show_close_button: true) do
Button { "Save" }
end
end
end
RUBY
end
render Components::ComponentSetup::Tabs.new(component_name: component)
render Docs::ComponentsTable.new(component_files(component))
end
end
end
5
Add RubyUI::DialogFooter to app/components/ruby_ui/dialog/dialog_footer.rb
# frozen_string_literal: true
module RubyUI
class DialogFooter < Base
def initialize(show_close_button: false, **attrs)
@show_close_button = show_close_button
super(**attrs)
end
def view_template
div(**attrs) do
yield if block_given?
close_button if @show_close_button
end
end
private
def default_attrs
{
class: "flex flex-col-reverse gap-2 sm:flex-row sm:justify-end"
}
end
def close_button
Button(variant: :outline, data: {action: "click->ruby-ui--dialog#dismiss"}) { "Close" }
end
end
end
6
Add RubyUI::DialogHeader to app/components/ruby_ui/dialog/dialog_header.rb
# frozen_string_literal: true
module RubyUI
class DialogHeader < Base
def view_template(&)
div(**attrs, &)
end
private
def default_attrs
{
class: "flex flex-col gap-2"
}
end
end
end
7
Add RubyUI::DialogMiddle to app/components/ruby_ui/dialog/dialog_middle.rb
# frozen_string_literal: true
module RubyUI
class DialogMiddle < Base
def view_template(&)
div(**attrs, &)
end
private
# No padding: DialogContent's gap-6 spaces the body, as in shadcn (vega).
def default_attrs
{}
end
end
end
8
Add RubyUI::DialogTitle to app/components/ruby_ui/dialog/dialog_title.rb
# frozen_string_literal: true
module RubyUI
class DialogTitle < Base
def view_template(&)
h2(**attrs, &)
end
private
def default_attrs
{
class: "font-heading leading-none font-medium",
data_ruby_ui__dialog_target: "title"
}
end
end
end
9
Add RubyUI::DialogTrigger to app/components/ruby_ui/dialog/dialog_trigger.rb
# frozen_string_literal: true
module RubyUI
class DialogTrigger < Base
def view_template(&)
div(**attrs, &)
end
private
def default_attrs
{
data: {
ruby_ui__dialog_target: "trigger",
action: "click->ruby-ui--dialog#open"
},
class: "inline-block"
}
end
end
end
10
Add dialog_controller.js to app/javascript/controllers/ruby_ui/dialog_controller.js
import { Controller } from "@hotwired/stimulus"
// Prefix for generated ids, unique per page (ruby-ui-dialog-1-title, …).
let dialogCount = 0
// Connects to data-controller="ruby-ui--dialog"
export default class extends Controller {
static targets = ["dialog", "title", "description", "trigger"]
static values = {
open: {
type: Boolean,
default: false
},
}
connect() {
this.closing = false
this.dialogTarget.addEventListener("close", this.handleClose)
this.dialogTarget.addEventListener("cancel", this.handleCancel)
this.dialogTarget.addEventListener("keydown", this.handleKeydown)
this.wireAria()
if (this.openValue) {
this.open()
}
}
disconnect() {
this.closing = false
this.dialogTarget.removeEventListener("close", this.handleClose)
this.dialogTarget.removeEventListener("cancel", this.handleCancel)
this.dialogTarget.removeEventListener("keydown", this.handleKeydown)
document.body.classList.remove("overflow-hidden")
}
open(e) {
e?.preventDefault()
// Reopening during the exit animation must not be closed by the stale animation promise.
this.closing = false
this.dialogTarget.dataset.state = "open"
this.dialogTarget.showModal()
document.body.classList.add("overflow-hidden")
this.setTriggersExpanded(true)
}
dismiss() {
this.animateClose()
}
// Plays the exit animation on the panel and its ::backdrop, then closes.
async animateClose() {
if (this.closing || !this.dialogTarget.open) return
this.closing = true
this.dialogTarget.dataset.state = "closed"
await Promise.allSettled(this.ownAnimations().map((animation) => animation.finished))
// handleClose/disconnect reset `closing`: the dialog already closed (e.g. a forced
// second Esc) and may have been reopened since, so don't close it again.
if (this.closing) this.dialogTarget.close()
}
// Only the dialog's own animations (panel + ::backdrop), never its descendants'.
ownAnimations() {
return document.getAnimations().filter((animation) => animation.effect?.target === this.dialogTarget)
}
// The panel's own padding also reports the <dialog> as target, so only a press
// that starts and ends outside the panel's rect counts as a backdrop click.
backdropPointerdown(e) {
this.pressStartedOutside = e.target === this.dialogTarget && this.isOutsidePanel(e)
}
backdropClick(e) {
const startedOutside = this.pressStartedOutside
this.pressStartedOutside = false
if (e.target !== this.dialogTarget) return
if (startedOutside && this.isOutsidePanel(e)) {
this.dismiss()
}
}
isOutsidePanel(e) {
const rect = this.dialogTarget.getBoundingClientRect()
return e.clientX < rect.left || e.clientX > rect.right || e.clientY < rect.top || e.clientY > rect.bottom
}
// Esc fires `cancel`; hold the native close so the exit animation can play.
// A dismissed <input type="file"> picker also fires a bubbling `cancel`; ignore it.
handleCancel = (e) => {
if (e.target !== this.dialogTarget) return
e.preventDefault()
this.animateClose()
}
// Native <dialog> lets Tab leave the last control for the browser UI before it
// wraps. Keep focus cycling inside, as the APG dialog pattern asks.
handleKeydown = (e) => {
if (e.key !== "Tab" || e.defaultPrevented || e.altKey || e.ctrlKey || e.metaKey) return
// A nested dialog handles its own Tab.
if (e.target.closest("dialog") !== this.dialogTarget) return
const tabbables = this.tabbables()
if (tabbables.length === 0) {
e.preventDefault()
return
}
const first = tabbables[0]
const last = tabbables[tabbables.length - 1]
const active = document.activeElement
if (e.shiftKey && (active === first || active === this.dialogTarget)) {
e.preventDefault()
last.focus()
} else if (!e.shiftKey && active === last) {
e.preventDefault()
first.focus()
}
}
// Candidates in the browser's sequential focus order: positive tabindex first,
// ascending, then tabindex 0 in DOM order (Array#sort is stable).
tabbables() {
const selector = "a[href], area[href], button, input, select, textarea, iframe, object, embed, summary, audio[controls], video[controls], [contenteditable], [tabindex]"
return [...this.dialogTarget.querySelectorAll(selector)]
.filter((el) =>
this.inTabOrder(el) &&
!el.matches(":disabled") && // also covers controls inside fieldset[disabled]
!el.closest("[inert]") &&
el.closest("dialog") === this.dialogTarget &&
this.isVisible(el)
)
.sort((a, b) => {
const ta = Math.max(a.tabIndex, 0)
const tb = Math.max(b.tabIndex, 0)
if (ta === tb) return 0
if (ta === 0) return 1
if (tb === 0) return -1
return ta - tb
})
}
// An explicit tabindex decides; otherwise the element is natively focusable.
// `tabIndex` reads -1 for an editing host and (in Chromium and WebKit) for
// <embed>, yet Tab reaches both. A contenteditable inside another is skipped.
inTabOrder(el) {
if (el.hasAttribute("tabindex")) return el.tabIndex >= 0
if (el.isContentEditable) return !el.parentElement?.isContentEditable
return el.localName === "embed" || el.tabIndex >= 0
}
// checkVisibility() landed in Safari 17.4; older engines fall back to layout boxes.
isVisible(el) {
if (typeof el.checkVisibility === "function") return el.checkVisibility({ visibilityProperty: true })
return el.getClientRects().length > 0
}
handleClose = () => {
this.closing = false
delete this.dialogTarget.dataset.state
document.body.classList.remove("overflow-hidden")
this.setTriggersExpanded(false)
}
// Names the dialog after its title/description and ties each trigger to it.
// Never overwrites ids or ARIA the author already set.
wireAria() {
const dialog = this.dialogTarget
const prefix = `ruby-ui-dialog-${++dialogCount}`
const dialogId = this.ensureId(dialog, `${prefix}-content`)
const title = this.ownTarget(this.titleTargets)
if (title) {
const titleId = this.ensureId(title, `${prefix}-title`)
if (!dialog.hasAttribute("aria-labelledby") && !dialog.hasAttribute("aria-label")) {
dialog.setAttribute("aria-labelledby", titleId)
}
}
const description = this.ownTarget(this.descriptionTargets)
if (description) {
const descriptionId = this.ensureId(description, `${prefix}-description`)
if (!dialog.hasAttribute("aria-describedby")) {
dialog.setAttribute("aria-describedby", descriptionId)
}
}
this.dialogId = dialogId
this.triggerControls().forEach((control) => {
if (!control.hasAttribute("aria-haspopup")) control.setAttribute("aria-haspopup", "dialog")
})
this.setTriggersExpanded(dialog.open)
}
// First target that lives inside this controller's own <dialog>.
ownTarget(targets) {
return targets.find((target) => this.dialogTarget.contains(target))
}
ensureId(element, id) {
if (!element.id) element.id = id
return element.id
}
// The element that carries the trigger's role: a button/link inside the
// trigger wrapper, or the menuitem/button that wraps it. A role-less wrapper
// gets no ARIA. The `closest` lookup intentionally climbs above the Dialog root
// for the dropdown pattern (DropdownMenuItem wraps the Dialog, see
// docs/app/views/docs/dropdown_menu.rb).
triggerControls() {
return this.triggerTargets
.map((trigger) => trigger.querySelector("button, a[href], [role=button]") || trigger.closest("[role=menuitem], [role=button]"))
.filter(Boolean)
}
// aria-controls is set only while open, as Base UI does. On close only a value
// pointing at this dialog is removed; one pointing elsewhere is the author's and
// stays. No state is kept, so a trigger added later or a reconnect (Turbo cache)
// behaves the same.
setTriggersExpanded(expanded) {
this.triggerControls().forEach((control) => {
control.setAttribute("aria-expanded", String(expanded))
if (expanded && !control.hasAttribute("aria-controls")) {
control.setAttribute("aria-controls", this.dialogId)
} else if (!expanded && control.getAttribute("aria-controls") === this.dialogId) {
control.removeAttribute("aria-controls")
}
})
}
}
11
Update the Stimulus controllers manifest file
rake stimulus:manifest:update12
Install required components
Component Dialog relies on the following RubyUI components. Refer to their individual installation guides for setup instructions:
Components
| Component | Built using | Source |
|---|---|---|
Dialog | Phlex | |
DialogContent | Phlex | |
DialogDescription | Phlex | |
DialogDocs | Phlex | |
DialogFooter | Phlex | |
DialogHeader | Phlex | |
DialogMiddle | Phlex | |
DialogTitle | Phlex | |
DialogTrigger | Phlex | |
DialogController | Stimulus JS |
